空調通風管道計算規則與方法心得

發布人：http://www.rdhw.com.cn   發布時間：2023-06-21 16:34:29

針對空調通風管道中不銹鋼風管的工程量計算規則與方法一些技巧心得，濟南通風管道廠小編給大家整理分享。

The editor of Jinan Ventilation Pipeline Factory has compiled and shared some tips and experiences on the calculation rules and methods of engineering quantities for stainless steel air ducts in air conditioning ventilation ducts.

1、薄鋼板風管

1. Thin steel plate air duct

（1）風管按不同規格以展開面積計算，管上檢查孔、測定孔、送風口、吸風口等所占面積不扣除。

(1) The air duct is calculated based on its expanded area according to different specifications, and the area occupied by inspection holes, measuring holes, air supply outlets, suction outlets, etc. on the duct is not deducted.

（2）計算風管長度時一律以圖注線長度為準，包括彎頭、三通、變徑管、天圓地方等管件的長度，但不得包括通風部件（如風閥、風口等）所在位置的長度。風管直徑和周長按圖注尺寸展開。但咬口風管的接口及翻邊量不得計算在展開面積內。

(2) When calculating the length of the air duct, the center line length in the drawing shall be used as the standard, including the length of pipes such as elbows, tees, variable diameter pipes, and circular areas, but it shall not include the length of the location of ventilation components (such as air valves, air vents, etc.). The diameter and perimeter of the air duct shall be expanded according to the dimensions indicated in the drawing. However, the interface and flange amount of the biting air duct shall not be calculated within the developed area.

（3）風管導流葉片按葉片的面積計算。

(3) The guide vanes of the air duct are calculated based on the area of the blades.

（4）風管附件（除軟性接頭按計算外），檢查孔、測定孔等按不同類型、規格分別以個為單位計算。

(4) Air duct accessories (excluding flexible joints calculated in square meters), inspection holes, measuring holes, etc. are calculated in units of different types and specifications.

2、不銹鋼風管及鋁板風管

2. Stainless steel air duct and aluminum plate air duct

風管的計算規則同薄鋼板風管，部件按設計成品重量計算。

The calculation rules for air ducts are the same as for thin steel plate air ducts, and the components are calculated based on the weight of the designed finished product.

3、塑料風管及部件

3. Plastic air ducts and components

（1）風管按圖注不同規格以展開面積計算，檢查孔、測定孔、送風口、吸風口等所占面積不扣除。

(1) The air duct is calculated based on the expanded area according to different specifications indicated in the drawing. The area occupied by inspection holes, measuring holes, air supply outlets, suction outlets, etc. is not deducted.

（2）計算風管長度時，一律以圖注線長度為準，包括彎頭、三通、變徑管、天圓地方等管件的長度，但不得包括通風部件（如風閥、風口等）所在位置的長度，風管直徑和周長以圖注尺寸展開。

(2) When calculating the length of air ducts, the length of the centerline indicated in the drawing shall prevail, including the length of fittings such as elbows, tees, variable diameter pipes, and circular areas, but shall not include the length of the location of ventilation components (such as air valves, air vents, etc.). The diameter and circumference of air ducts shall be expanded based on the dimensions indicated in the drawing.

（3）標準部件和非標準部件均按成品的重量計算。

(3) Both standard and non-standard components are calculated based on the weight of the finished product.

導流葉片計算：

Calculation of guide vanes:

導流葉片的作用：是將從空氣調節主機壓出通過交換的冷氣，順著風管從風口排除，達到調節室內空氣的目的。當冷氣通過風管彎頭處時，如果不對其進行導流，勢必產生渦流影響冷氣傳導！因此風管彎頭處必須安裝導流葉片！往往有一些年輕筒子們忽視導流葉片計算，要么就過估很不準確。小編提供列表計算如下：

The function of the guide vane is to press out the exchanged cold air from the air conditioning host and exhaust it from the air outlet along the air duct, achieving the purpose of regulating indoor air. When cold air passes through the bend of the air duct, if it is not guided, eddy currents will inevitably affect the conduction of cold air! Therefore, guide vanes must be installed at the elbow of the air duct! Often, some young tube workers overlook the calculation of guide vanes, or overestimate and make inaccurate predictions. The list provided by the editor is calculated as follows:

風管導流葉片長邊確定片數表：

Table for determining the number of blades on the long side of the air duct guide vanes:

1、根據風管長邊規格尺寸選擇相對應導流葉片的片數。

1. Select the corresponding number of guide vanes based on the specifications and dimensions of the long side of the air duct.

2、根據風管短邊規格尺寸選擇相對應導流葉片單片面積數×根據長邊尺寸已選定的導流葉片片數=該規格的風管導流葉片總面積。

2. Select the corresponding number of single guide vane areas based on the specifications and dimensions of the short side of the air duct × The number of selected guide vanes based on the size of the long side=the total area of the guide vanes in the duct of that specification.

驗收規范中規定當平面寬度大于或等于500mm時都應設置導流葉片，那么以上兩種情況都應計算導流葉片的工程量。

The acceptance specification stipulates that guide vanes should be installed when the plane width is greater than or equal to 500mm, and the engineering quantity of guide vanes should be calculated for both cases.
