清洗通風管道這些方法要用上！

發布人：http://www.rdhw.com.cn   發布時間：2021-08-12 16:51:43

一。機器設備及專用工具搬到選定地址，并拿布遮蓋好施工點下邊的物件。

One. Move the machinery, equipment and special tools to the selected address, and cover the objects under the construction site with cloth.

第二。將需清潔的空調風管系統分成數個清潔施工段，明確施工切入點，用電剪切割機切下500×400毫米的開口。

Second. Divide the air conditioning duct system to be cleaned into several cleaning construction sections, clarify the construction entry point, and cut 500 pieces with an electric shear cutter × 400 mm opening.

第三。用氣囊塞入清潔管段兩邊后對氣囊充氣，氣囊規格適宜管道尺寸并產生完善的封閉，充分的隔離清潔區和非清潔區，防止二次環境污染。

Third. Insert the air bag into both sides of the cleaning pipe section and inflate the air bag. The specification of the air bag is suitable for the pipe size and produces a perfect closure. Fully isolate the clean area and non clean area to prevent secondary environmental pollution.

眉山通風管道眉山通風管道

Meishan ventilation duct Meishan ventilation duct

第四。將清潔施工段中間的每個出風口封堵，只留與兩邊隔開氣囊接近的2個出風口。

Fourth. Block each air outlet in the middle of the cleaning construction section, leaving only two air outlets close to the separated airbags on both sides.

第五。將以上所述2個出風口百葉與其他出風口百葉一塊兒開展清潔，并裝上各自配有吸塵器接口。壓縮空氣管穿孔與監測器線越過孔的封板。

Fifth. Clean the above two air outlet louvers together with other air outlet louvers, and install them with vacuum cleaner interfaces. The compressed air pipe is perforated and the monitor line crosses the sealing plate of the hole.

第六。將清潔風管段堵上，很多不必要出風口孔洞用其他板材與風管底邊暫時補平，以便清潔機器人能在眉山通風管道內圓滿通過。

Sixth. The cleaning air duct section is blocked, and many unnecessary air outlet holes are temporarily leveled with the bottom edge of the air duct with other plates, so that the cleaning robot can pass through the Meishan ventilation duct successfully.

第七。將配有清潔毛刷和監測器探頭的機器人或有高壓空氣接管的高壓雙向噴頭，從清潔管段的運行孔放進風管內。

Seventh. Place the robot equipped with cleaning brush and monitor probe or the high-pressure two-way nozzle with high-pressure air connection into the air duct from the running hole of the cleaning pipe section.

第八。打開壓縮空氣機和吸塵器，使其有旋轉毛刷的機器人或高壓空氣噴頭對風管內壁由近而遠開展刷噴清潔，依據監測器探頭操縱機器人作業。當風管管徑不大于３００×１５０mm時，機器人沒法進到時由高壓噴頭或軟軸毛刷開展清潔，清潔同時開展全過程錄影。

Eighth. Turn on the compressed air machine and vacuum cleaner, make the robot with rotating brush or high-pressure air nozzle clean the inner wall of the air duct from near to far, and operate the robot according to the monitor probe. When the diameter of air duct is no more than 300 × When the robot cannot enter at 150mm, the cleaning shall be carried out by high-pressure nozzle or flexible shaft brush, and the whole process video shall be carried out at the same time.

第九。對圓型風管與螺旋圓風管及其方圓型彎頭，都能夠用機器人監測器，高壓噴頭，噴槍替換運用開展清潔。

Ninth. For round air duct, spiral round air duct and its square and round elbow, robot monitor, high-pressure nozzle and spray gun can be replaced for cleaning.
